DESCRIPTION
Fitments
| Years |
Make |
Model |
| 1986 - 2003 |
Harley-Davidson |
Sportster 883 XLH |
Features
Stainless steel conversion kit includes only what's needed to convert your head to the long-life stainless steel Black Diamond™ intake valvesExtend the life of the valvetrain and intake components by as much as 4x over the OEM titanium partsIncludes forged one-piece stainless steel intake valves, wound chrome-silicon heat-treated wire valve springs, ultra-light titanium retainers and hardened steel basesComponents are created using Finite Element Analysis (F.E.A.) software, as well as proprietary camshaft analysis and spring design softwareSpecifically designed and engineered for each applicationMade in the U.S.A.Specs
Riding Style: Street
Product Name: Spring Kit
Spring Open Pressure: 371 lb
Spring Seat Pressure: 178 lb
Units: Kit
Application: Exhaust
Spring Lift: 0.660"
Application: Intake
Spring Lift: 0,660"Approximate Package Weight & Dimensions
Weight: 1.25
Height: 2.26
Length: 10.3
Width: 4.4
