Wear Bar - Trail Blazer IV™ Flat-Top® - 6" - 60° - Lutzka's Garage

WOODY'S

Wear Bar - Trail Blazer IV™ Flat-Top® - 60°

TYV4-6250

$113.48

-+

Ask about this product

DESCRIPTION


Fitments

Years Make Model
1971 - 1973 Yamaha SR 433
1980 - 1986 Yamaha SRV 540
1981 - 1984 Yamaha Excel III 340
1983 - 1986 Yamaha V-Max 540
1991 - 1993 Yamaha Exciter II 570
1991 - 1993 Yamaha Exciter II 570 LE
1982 - 1993 Yamaha Bravo 250
1972 - 1973 Yamaha SR 643
1970 Yamaha SS 338
1970 Yamaha SS 396
1971 Yamaha SS 433
1971 Yamaha SW 433 E
1972 - 1973 Yamaha GP 643
1973 Yamaha SR 292
1978 Yamaha SSR
1986 - 1991 Yamaha CF 300 Inviter
1971 - 1973 Yamaha SL 292
1993 - 1995 Yamaha Enticer II 410 LT
1972 - 1973 Yamaha EW 643
1970 Yamaha SL 396
1979 - 1980 Yamaha Enticer 340 E
1972 - 1973 Yamaha EW 433
1985 - 1990 Yamaha XL-V 540
1996 - 1997 Yamaha Venture 480 TR
1991 - 1997 Yamaha Venture 500 XL
1985 - 1986 Yamaha Phazer 480 E
1990 - 1996 Yamaha Phazer II 480
1997 - 1998 Yamaha Phazer 480 SS Electric
1990 - 1999 Yamaha Ovation LE
1987 Yamaha Bravo 250 T
1989 - 1991 Yamaha Ovation 340
1984 - 1989 Yamaha Phazer
1987 - 1989 Yamaha Phazer 480 Deluxe
1990 - 1996 Yamaha Phazer II 480 LE
1996 Yamaha Phazer II 480 Mountain Lite
1990 - 1991 Yamaha VK 540 E
1974 - 1975 Yamaha GPX 338
1974 - 1975 Yamaha GPX 433
1997 - 1998 Yamaha Phazer 480 SS
1989 Yamaha Ovation Deluxe
1998 Yamaha Venture 480 TR Electric
1988 - 1989 Yamaha VK 540
1994 - 1998 Yamaha VK 540 II
1976 Yamaha SRX 340
1971 Yamaha SW 396
1971 Yamaha GP 396
1997 Yamaha V-Max 4 800
1973 Yamaha EL 433
1993 Yamaha Exciter II 570 ST
1993 Yamaha Exciter II 570 SX
1992 - 1993 Yamaha Venture 480 GT
1991 - 1995 Yamaha Phazer II 480 ST
1997 - 1999 Yamaha Phazer 500 Mountain Lite
1968 Yamaha SL 350
1984 Yamaha Phazer 480 Special Edition
1969 Yamaha SL 351
1998 - 2000 Yamaha Bravo 250 LT
1976 - 1981 Yamaha SRX 440
1999 - 2004 Yamaha VK 540 III

Video


Features

  • Excellent high-speed cornering control
  • 1/2 host runner features 6 of 60 sharp edge turning carbide
  • Wear pads are a full 1-1/2 long
  • Full-length hardweld surfaces between all three carbide inserts provide extended wear
  • Extra-long studs make it easy to install plastic ski skins
  • Track studding recommended
  • Features 6 of 60 carbide
  • 1/2 round bar with Flat-Top design
  • Provides safety and control for both studded and un-studded sleds

    • Specs

  • Type: Single Runner
  • Material: Carbide
  • Wear Bar Profile: Round
  • Carbide Runner Angle: 60
  • Model: Trail Blazer lV
  • Units: Pair
  • Bar Diameter: 0.50"
  • Carbide Runner Length: 6.00"
  • Number of Studs: 4
  • Product Name: Wear Bar
  • Riding Style: Snow
  • Wear Pads: Two 1.50" Carbide Wear Pads

    • Approximate Package Weight & Dimensions

  • Weight: 3.25
  • Height: 0.71
  • Length: 24.5
  • Width: 5.4
