Features
Constructed of high-strength seamless double-butted 2014-T6 alloyEach handlebar has been shot-peened and hard anodized for improved durabilityOversized 1-1/8 clamp diameter improves bar/clamp grip (requires "oversized" bar mounts)Lightly Knurled left slide helps with grip bar adhesion, without interfering with Lock-On GripsIncludes injection-molded high-density ODI foam bar pad
Specs
Center Width: 14 cm (5-1/2")
Center Width: 5-1/2"
Controls Diameter: 22 mm (7/8")
Features: Includes Pad
Pullback/Sweep: 50 mm
Rise: 2-3/32"
Units: Each
Handlebar Diameter: 1-1/8"
Handlebar Diameter: 28.6 mm
Height: 88 mm
Product Name: Handlebar
Pullback/Sweep: 50 mm (1-15/16")
Pullback/Sweep: 1-15/16"
Riding Style: Off-Road
Rise: 53 mm (2-3/32")
Width: 779 mm (30-5/8")
Width: 779 mm
Center Width: 14 cm
Clamping Diameter: 28,6 mm (1-1/8")
Clamping Diameter: 1-1/8"
Clamping Diameter: 28.6 mm
Controls Diameter: 7/8"
Controls Diameter: 22 mm
Material: 2014-T6 Alloy
Rise: 53 mm
Type/Bend: MX
Type/Bend: Schoolboy
Clamping Width: 140 mm (5-1/2")
Handlebar Diameter: 28,6 mm (1-1/8")
Height: 88 mm (3-1/2")
Height: 3-1/2"
Width: 30-5/8"
Approximate Package Weight & Dimensions
Weight: 1.8
Height: 2.25
Length: 30.75
Width: 6.25
